8 inch TFT LCD Display Module 1024x768 LVDS Interface
Informations
Resolution
1024x768
Interface
LVDS
Voltage
5V
Temperature
-20°C ~ 70°C
Wide Viewing Angle
Yes
Outline
183. 43 × 138.35 × 3.75(mm)
Size
8"
Active Area
162.05 × 121.54(mm)
Brightness：450 cd/m²
TM080TDGP01 from Tianma is a 8 inches TFT LCD display module,1024(RGB)x768 resolution. It is a transmissive TFT LCD with white LED backlight, wide viewing angle.
